LiFePo4 series Battery
Model | LFP-5 | | LFP-10 | LFP-15 | LFP-30 | LFP-50 |
Nominal Capacity | 5kWh | 10kWh | 15kWh | 30kWh | 50kWh |
Usable Capacity | 4.75kWh | 9.5kWh | 14.25kWh | 28.5kWh | 47.5kWh |
Voltage Range | 44.8-57.6V | 44.8-57.6V | 44.8-57.6V | 44.8-57.6V | 44.8-57.6V |
Nominal Capacity (Ah) | 100Ah | 200Ah | 300Ah | 600Ah | 1000Ah |
Max. Continuous Discharge Current | 100A | 200A | 300A | 600A | 1000A |
Max. Continuous Charge Current | 50A | 100A | 150A | 300A | 500A |
Peak Discharge Current (30s) | 150A | 300A | 450A | 900A | 1500A |
Recommended Charge Current | 50A | 100A | 150A | 300A | 500A |
Cycle Life (80% DoD) | >6,000 cycles | >6,000 cycles | >6,000 cycles | >6,000 cycles | >6,000 cycles |
Round Trip Efficiency | | >95% | >95% | >95% | >95% | >95% |
Self-Discharge Rate | <2% per month | <2% per month | <2% per month | <2% per month | <2% per month |
Communication Protocol | CAN/RS485 | CAN/RS485 | CAN/RS485 | CAN/RS485 | CAN/RS485 |
Monitoring | Integrated | Integrated | Integrated | Integrated | Integrated |
Operating Temperature (Discharge) | -10°C to +50°C | -10°C to +50°C | -10°C to +50°C | -10°C to +50°C | -10°C to +50°C |
Operating Temperature (Charge) | 0°C to +50°C | 0°C to +50°C | 0°C to +50°C | 0°C to +50°C | 0°C to +50°C |
Storage Temperature | -20°C to +60°C | -20°C to +60°C | -20°C to +60°C | -20°C to +60°C | -20°C to +60°C |
Humidity | 5-95% non-condensing | 5-95% non-condensing | 5-95% non-condensing | 5-95% non-condensing | 5-95% non-condensing |
Dimensions (W×H×D) | 480×360×170mm | 480×500×170mm | 480×650×170mm | 600×1200×600mm | 600×2000×600mm |
Weight | 48kg | 95kg | 140kg | 280kg | 480kg |
Enclosure Rating | IP55 | IP55 | IP55 | IP20 | IP20 |
Cooling | Natural Convection | Natural Convection | Natural Convection | Forced Air | Forced Air |
Scalability | Up to 16 in parallel | Up to 16 in parallel | Up to 16 in parallel | Up to 8 in parallel | Up to 8 in parallel |
Warranty | 10 Years | 10 Years | 10 Years | 10 Years | 10 Years |
